Bộ nguồn sin chuẩn Apollo DC AC Inverter 110VDC-220VAC

  • Mã sản phẩm: SET110-220
  • Trạng thái: Còn hàng
0
  • Bộ nguồn Sin chuẩn Inverter 110VDC - 220VAC chuyên dùng cho các thiết bị viễn thông.
  • Chuyển mạch nhanh, Đầu vào giải rộng 101V - 127V.
  • Thiết kế chuẩn dạng rack có thể lắp vào tủ rack.
  • Có sạc acquy khi sử dụng đầu vào DC là ắc quy.
  • Bảo hành: 12 tháng.
Số lượng:
- +
  • Giao hàng toàn quốc
  • Miễn phí giao hàng nội thành Hà Nội
  • Hàng chính hãng
  • Giao hàng Toàn Quốc
  • Đổi trả trong vòng 7 ngày
BẠN CẦN TRỢ GIÚP

Gọi ngay: Hotline: 0936396998 - 024.39.158.999 - KT & Bảo hành:

CSKH: 02439.158.999 - 0936.396.998

Làm việc từ: 8h - 17h00

Đặc điểm nổi bật

1. With micro-CPU control, the circuit is simple and reliable. High efficiency >85%. Adopting SPWM technology, with the output is pure sine wave with stabilized voltage and frequency,filtering noise and low distortion.

2. 1-4kva pure sine wave inverter built-in bypass switch, it can quickly switch between the mains and the inverter.

3. It can work without DC power. This function allows to use the inverter in advance, and install the battery.

4. Support communication function; RS232/RS485/RJ45 interface for choose. Provide three groups of passive dry contact: DC input failure, the mains failure and AC output failure alarm.

5. Mold design alone, coated paint, beautiful and generous, light weight. 1U, 2U, 4U or 8U 19 inch rack mounting design, easy to use.

Thông số kĩ thuật


  Output power

1KVA

2KVA

3KVA

4KVA

5KVA

6KVA

7KVA

8KVA

9KVA

10KVA

Run mode

Pure inverter/online interactive

DC
  Input

Rated input voltage

110V/220V

Rated input current(A)

10.6/
  5.3

21.3/
  10.5

32/
  15.8

42.6/21.1

53.2/26.3

63.8/
  31.6

74.5/
  36.8

81.5/
  42.1

95.7/47.4

106.4/52.6

Turn-off voltage range

110Vdc(92V-132V)   220Vdc(190V-270V)

Turn-on voltage range

110Vdc(101V-127V)   220Vdc(207V-260V)

Anti-noise current irrigation

≤10%

AC
  Input

Bypass voltage

145V-95V(±10V)

Rated input current(A)

10.5

21.1

31.6

42.1

52.6

63.2

73.7

84.2

94.7

105.3

Bypass transfer time(ms)

≤5ms

AC
  output

Power factor

0.8

0.7

Rated capacity(VA)

1K

2K

3K

4K

5K

6K

7K

8K

9K

10K

Rated output power

800W

1600W

2400W

3200W

3500W

4200W

4900W

5600W

6300W

7000W

Rated output voltage and frequency

110Vac, 50Hz

Wave shape

Pure sine wave

Rated output current

7.2A

14.5A

21.8A

29.1A

31.8A

38.2A

44.5A

50.9 A

57.3 A

63.6 A

Output voltage accuracy

110 V±1.5%

Output frequency accuracy

50Hz±0.1%

Waveform distortion

≤3%

Dynamic Response Time

0.05

Overload

120%, 30s

Inverter efficiency
  (80% Resistive load)

≥85%

Work
  condition

Dielectric Strength

input & output 1500Vac, 1min

Noise(1m)

≤40dB

Ambient temperature

-25℃~+50℃

Humidity

0~95%, Non-condensing

Altitude(m)

≤1500

Cooling

Forced air

Interface

HMI

LCD+LED display

Communication interface

RS232/RS485/RJ45(Choose one)

dry contact load output

2ch /3ch output ( Choose one)

Protection

Input under/over voltage; output overload, short   circuit protection; AC input high and low voltage protection

Output wiring

Sockets and terminals

Terminal Blocks
