| SPECIFICATIONS BATTERY CHARGER | ||||
| MODEL | AC1210A | AC2403A | AC2405A | AC2410A |
| AC Input | 195VAC-220VAC | |||
| DC Output Voltage | 13,2V-13.8V | 26,4V-27,6V | ||
| Max current output | 10A | 3A | 5A | 10A |
| Frequency | 50Hz-60Hz | |||
| Convert Efficiency | 85-95% | |||
| Three Stage Charging | CC,CV,FC | |||
| Over Current Protection | Yes | |||
| Over Voltage Protection | Yes | |||
| Short Circuit Protection | Yes | |||
| Polarity Error Protection | Yes | |||
| Over charge protection | Yes | |||
| Operating Junction Temperature | -55°C to +150°C | |||
| Storage Temperature | -65°C to +150°C | |||
| Lead Temperature (Soldering, 10 Seconds) | 300°C | |||
| Working Temperature | (-5) - 40°C | |||
| Color | Gray | |||
| AC Plug | Yes | |||
| DC Plug | Yes | |||
| Product Dimension(mm) | 230 x 115 x 90 | |||
| Battery | ≤100Ah | ≤2x30Ah | ≤2x55Ah | ≤2x100Ah |
